Stalling this gearmotor could cause gear damage.
Output Shaft Style | D-shaft |
---|---|
Motor Type | Brushed DC |
Output Shaft Support | Brass Case |
Gear Material | Metal |
Weight | 0.42 oz (12g) |
Voltage (Nominal) | 12V |
Voltage Range (Recommended) | 6V - 12V |
Speed (No Load @ 12VDC) | 130 rpm |
Current (No Load @ 12VDC) | 70mA |
Current (Stall @ 12VDC) | 1600mA |
Torque (Stall @ 12VDC) | 50 oz-in |
Gearbox Style | Straight Cut Spur |
Connector Type | ZH Series JST 6-pin connector (1.5mm Pitch) |
Encoder: Cycles Per Revolution (Motor Shaft) | 3 |
Encoder: Countable Events Per Revolution (Output Shaft) | 2,527.0874 |
Gear Ratio | 210.591:1 |
Encoder Type | Relative, Quadrature |
Encoder Sensor Type | Magnetic (Hall Effect) |
