Premium N20 Gear Motor (150:1 Ratio, 175 RPM, with Encoder)
SKU:
$19.99
Tech Tip
Stalling this gearmotor could cause gear damage.
Downloads
Specs
| Output Shaft Style | D-shaft |
|---|---|
| Motor Type | Brushed DC |
| Output Shaft Support | Brass Case |
| Gear Material | Metal |
| Weight | 0.42 oz (12g) |
| Voltage (Nominal) | 12V |
| Voltage Range (Recommended) | 6V - 12V |
| Speed (No Load @ 12VDC) | 175 rpm |
| Current (No Load @ 12VDC) | 70mA |
| Current (Stall @ 12VDC) | 1600mA |
| Torque (Stall @ 12VDC) | 45 oz-in |
| Gearbox Style | Straight Cut Spur |
| Connector Type | ZH Series JST 6-pin connector (1.5mm Pitch) |
| Encoder: Cycles Per Revolution (Motor Shaft) | 3 |
| Encoder: Countable Events Per Revolution (Output Shaft) | 1,808.3333 |
| Gear Ratio | 150.694:1 |
| Encoder Type | Relative, Quadrature |
| Encoder Sensor Type | Magnetic (Hall Effect) |
