Premium N20 Gear Motor (10:1 Ratio, 2600 RPM)
SKU:
$12.99
Tech Tip
Stalling this gearmotor could cause gear damage.
Specs
| Output Shaft Style | D-shaft |
|---|---|
| Motor Type | Brushed DC |
| Output Shaft Support | Brass Case |
| Gear Material | Metal |
| Weight | 0.34 oz (9.5g) |
| Voltage (Nominal) | 12V |
| Voltage Range (Recommended) | 6V - 12V |
| Speed (No Load @ 12VDC) | 2600 rpm |
| Current (No Load @ 12VDC) | 120mA |
| Current (Stall @ 12VDC) | 1600mA |
| Torque (Stall @ 12VDC) | 4 oz-in |
| Gearbox Style | Straight Cut Spur |
| Connector Type | Male Spade Terminal |
| Gear Ratio | 10:1 |
