Stalling this gearmotor could cause gear damage.
Output Shaft Style | D-shaft |
---|---|
Motor Type | Brushed DC |
Output Shaft Support | Dual Ball Bearing |
Gear Material | Metal |
Weight | 3.56 oz (101g) |
Voltage (Nominal) | 12V |
Voltage Range (Recommended) | 3V -12V |
Speed (No Load @ 12VDC) | 44 rpm |
Current (No Load @ 12VDC) | 0.21A |
Current (Stall @ 12VDC) | 4.9A |
Torque (Stall @ 12VDC) | 347 oz-in (25 kgf-cm) |
Gearbox Style | Planetary |
Connector Type | Male Spade Terminal |
Gear Ratio | 270:1 |
