Overlander-4 All-Terrain Robot Platform (25lb Payload, 3.8mph)
SKU:
The Overlander-4 is a rugged, R/C-operated, outdoor-ready mobile robotics platform that's ready to assemble right out of the box. Whether you have a project or two under your belt, or you're just starting out as a builder, the Overlander-4 has what you need to bring your ideas into the outoors in a big way!
Built for the Outdoors
What’s more outdoors than outer space? While the Overlander-4 is designed to conquer the variety of Earthly environs, its futuristic “tweels” share their airless, flat-free, and ruggedly treaded qualities with interplanetary robot wheels that have rolled on the Moon and Mars! The Overlander-4's Wasteland Wheels provide excellent shock absorption and amazing all-terrain traction via grippy rubber conformation around irregular surfaces.
The minimalist design of the Overlander-4’s exterior leaves little room for anything to go wrong when traversing terrain. The flat underbelly is tucked-up tight to maximize ground clearance, and the flat surface can function as a skid plate when duty calls. Positive-drive steel axles make sure that the drive torque transfers to the ground—there’s zero chance of drivetrain slip!
Crafted for Creativity
The Overlander-4’s interior is clean and tidy, providing a neat home to its wires and electronics while leaving ample room for the bevy of your own big ideas. There’s an insistent invitation for you to bolt something onto the top and utilize the Overlander’s hefty 25 lbs payload—the essential goBILDA® pattern can be found on all corners of the bot! Included debris shields for any unused holes help to keep the terrain out of the Overlander-4’s internals.
Everything's Included
All the electronics you need are included for you to get up-and-running right after assembly. It's also super easy to add electronics like lights and to power distribution boards to your Overlander-4 project. Check out an R&D-curated list of highly compatible products below!
⚠️Li-ion Battery Safety Notice:Lithium ion Batteries can be dangerous. Please read these safety instructions as well as our warranty and return policy for Li-ion batteries.
Battery Compatibility
The Overlander-4 comes with a 20V, 6Ah Li-ion Battery. It is also compatible with the following batteries (via its goBILDA® Smart Dock, and accounting for the dimensions of the Overlander-4’s internals):
- DEWALT® 20V MAX batteries.
- DEWALT® 18V XR Batteries*. This branding is used outside of the USA for many DEWALT® slide-in style flat-top batteries. 18V XR batteries are slide-in style, unlike the bottom-insert style of DEWALT® NiMH batteries, which are branded as 18V in the US and are NOT compatible.
Specs
| Weight | 13.45lbs (6.1kg) With Battery |
|---|---|
| Max Payload | 25lbs (11kg) |
| Max Speed | 3.88 mph (1.73 m/s ) |
| Runtime | ~45 minutes |
